Datasheet

ANT-W63WS1 Series

Radiation Efficiency

Radiation efficiency (Figure 8), shows the ratio of power delivered to the antenna relative to the power

radiated at the antenna, expressed as a percentage, where a higher percentage indicates better

performance at a given frequency.

100

2300 2650 3000 3350 3700 4050 4400 4750 5100 5450 5800 6150 6500 6850 7200

Frequency (MHz)

Figure 8. W63WS1 Series Antenna Radiation Efficiency, Straight
