Data Sheet

ADL5387

Rev. C | Page 7 of 27

TYPICAL PERFORMANCE CHARACTERISTICS

VS = 5 V, TA = 25°C, LO drive level = 0 dBm, RBIAS = open, unless otherwise noted.

200

400

600

800 1000 1200 1400 1600 1800 2000

RF FREQUENCY (MHz)

GAIN

INPUT P1dB

TA = +85°C

TA = +25°C

TA = –40°C

Figure 3. Conversion Gain and Input 1 dB Compression Point (IP1dB) vs.

RF Frequency

100 110

120 130

FREQUENCY (MHz)

INPUT P1dB

GAIN

TA = +85°C

TA = +25°C

TA = –40°C

Figure 4. Conversion Gain and Input 1 dB Compression Point (IP1dB) vs.

RF Frequency (Low Frequency Range)

200

400

600

800 1000 1200 1400 1600 1800 2000

RF FREQUENCY (MHz)

TA = –40°C

TA = +25°C

TA = +85°C

Q CHANNEL

I CHANNEL

INPUT IP3

(I AND Q CHANNELS)

INPUT IP2

Figure 5. Input Third-Order Intercept (IIP3) and

Input Second-Order Intercept Point (IIP2) vs. RF Frequency

100 110 120 130

FREQUENCY (MHz)

IIP2

IIP3

TA = –40°C

TA = +25°C

TA = +85°C

Figure 6. Input Third-Order Intercept (IIP3) and Input Second-Order Intercept

Point (IIP2) vs. RF Frequency (Low Frequency Range)

2.0

1.5

1.0

0.5

–0.5

–1.0

–1.5

–2.0

200

400

600

800 1000 1200 1400 1600 1800 2000

RF FREQUENCY (MHz)

TA = +85°C

TA = +25°C

TA = –40°C

Figure 7. I/Q Gain Mismatch vs. RF Frequency

–2.0

–1.5

–1.0

–0.5

0.5

1.0

1.5

2.0

100 110 120 130

FREQUENCY (MHz)

TA = –40°C

TA = +25°C

TA = +85°C

Figure 8. I/Q Gain Mismatch vs. RF Frequency (Low Frequency Range)
