www.littelfuse.com

Power Distribution Centers

TERMINAL TYPE 1

Terminal Loks

Description

Wire Diam.

Type of terminal loks

For part number: 354501 / 354502 / 354503

0.50 - 2 mm2

For part number: 354501 / 354502 / 354503

0.50 - 2 & 3.3 - 5.3 mm2

For part number: 354501 / 354502

0.50 - 2 mm2

For part number: 354502

0.50 - 2 mm2

Ratings

Part Number

Description

Wire Diam.

Material

913-070 (Reeled per 2200 pcs)

Heavy Duty + spring clip*

0.5-0.8 mm² / 18-20AWG

Brass

0913070001 (Single per 250 pcs)

0.5-0.8 mm² / 18-20AWG

913-071 (Reeled per 2200 pcs)

Heavy Duty + spring clip*

1.33-2.09 mm² / 14-16AWG

Brass

913-071XS (Reeled per 2200 pcs)

1.33-2.09 mm² / 14-16AWG

Silver plated copper

0913071001 (Single per 250 pcs)

Heavy Duty + spring clip*

1.33-2.09 mm² / 14-16AWG

Brass

913-072 (Reeled per 2200 pcs)

3.32-5.37 mm² / 10-12AWG

913-072XS (Reeled per 2200 pcs)

Heavy Duty + spring clip*

3.32-5.37 mm² / 10-12AWG

Silver plated copper

0913072001 (Single per 250 pc)

3.32-5.37 mm² / 10-12AWG

Brass

913-058 (Reeled per 4500 pcs)

Standard Duty

0.5-0.8 mm² / 18-20AWG

Brass

0913058001 (Single per 250 pcs)

0.5-0.8 mm² / 18-20AWG

913-059 (Reeled per 4500 pcs)

Standard Duty

1.33-2.09 mm² / 14-16AWG

Brass

0913059001 (Single per 250 pcs)

1.33-2.09 mm² / 14-16 AWG

913-060 (Reeled per 4500 pcs)

Standard Duty

3.32-5.37 mm² / 10-12AWG

Brass

0913060001 (Single per 250 pcs)

3.32-5.37 mm² / 10-12AWG

* Spring clip material:

Stainless steel
