Non return valve

VMPA2-RV

Part number: 8039821

Data sheet

Feature

Value

Valve function

Unlockable non-return function

Actuation type

Pneumatic

Type of mounting

Clip

Standard nominal flow rate

330 l/min

Operating pressure

0.05 MPa ... 0.8 MPa

Operating pressure

0.5 bar ... 8 bar

Pilot pressure MPa

0.05 MPa ... 0.8 MPa

Pilot pressure

0.5 bar ... 8 bar

Pilot pressure psi

7.25 psi ... 116 psi

Ambient temperature

-5 °C ... 50 °C

Housing material

POM

Operating medium

Compressed air as per ISO 8573-1:2010 [7:4:4]

Mounting position

Any

Actuation type, piloted non-return function

Pneumatic

Operating pressure for entire temperature range

0.5 bar ... 8 bar

Information on operating and pilot media

Operation with oil lubrication possible (required for further use)

Corrosion resistance class (CRC)

4 - Particularly high corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Storage temperature

-20 °C ... 40 °C

Temperature of medium

-5 °C ... 50 °C

Pilot medium

Compressed air as per ISO 8573-1:2010 [7:4:4]

Product weight

0.19 g

Note on materials

RoHS-compliant

Seals material

NBR

8/7/22 - Subject to change - Festo SE & Co. KG

1/1
