background image
Technical Data 10953
Effective December 2020
Supersedes February 2020
FP1012V
High frequency, high current power inductors
Applications
•
Multi-phase and Vcore regulators
•
Voltage regulator modules (VRMs) and high
power density VRMs
•
Server and desktop
•
Central processing unit (CPU)
•
Graphics processing unit (GPU)
•
Application specific integrated circuit
(ASIC)
•
Data networking and storage systems
•
Graphics cards and battery power systems
•
Point-of-Load modules
Environmental compliance and general
specifications
•
Storage temperature range (component):
-40 °C to +125 °C
•
Operating temperature range: -40 °C to +125 °C
(ambient plus self-temperature rise)
•
Solder reflow temperature:
J-STD-020 (latest revision) compliant
Pb
HALOGEN
HF
FREE
Product features
•
Vertical design utilizes less board space
•
High current carrying capacity
•
Operating frequency up to 3 MHz
•
Inductance range from 70 nH to 470 nH
•
Current range 22 A to 190 A
•
10.0 mm x 6.0 mm footprint surface mount
package in 12 mm height
•
Moisture sensitivity level (MSL): 1
•
Ferrite core material
•
Weight: 3.1 grams typical
