PJA100F-48-R datasheet(3/16 Pages) COSEL

3 / 16 page

PJA-3

Point A

Mounting hole

(Bottom side)

3-M3

Mounting hole

Terminal cover

2-M3

CN4

Connector for

Remote ON/OFF (option)

M3.5

Name plate

AC(L)

AC(N)

FG( )

Output terminal(–)

Output terminal(+)

Output voltage

adjustable potentiometer

LED

101

66.5±0.5

33.5

12.5max

109

19.5

76±0.5

[0.77]

[0.49]

[4.29]

[2.99]

[0.16]

[3.98]

[1.32]

[2.62]

14±1.5

[0.55]

15.3±1.5 (LED)

[0.6]

11.2±1.5 (potentiometer)

[0.44]

¶ Tolerance : ±1 [±0.04]

¶ Weight : 500g max

¶ PCB Material/thickness : FR-4 / 1.6mm [0.06inches]

¶ Chassis material : Aluminum

¶ Cover material : Galvanizing steel

¶ Dimensions in mm, [ ]=inches

¶ Mounting torque : 0.49N-m max

¶ Screw tightening torque : M3.5 1.0N-m max

¶ Connect the input FG to safety earth ground.

PJA100F

External view

Features

*1 This is the result of measurement of the testing board with

capacitors of 22mF and 0.1mF placed at 150 mm from the

output terminals by a 20 MHz oscilloscope or a ripple-noise meter

equivalent to Keisoku-Giken RM103.

See 1.6 of Instruction Manual for more details.

When the load factor is 0 - 30%, the switching power loss is

reduced by burst operation, which will cause ripple and ripple

noise to go beyond the specifications.

*2 Drift is the change in DC output for an eight hour period after a half-

hour warm-up at 25C.

*3 Consult us about dynamic load and input response. Measure the output

voltage by using the average mode of the tester to deal with the burst

operation at 30% load or less.

*4 Output power derating is required. Refer to “Derating”.

*5 See 4 in Instruction Manual for more details.

*6 Consult us about safety agency approvals for the models with optional functions.

*7 Consult us about other classes.

*8 The RC terminal is added to option –R models. The RC terminal is isolated

Block diagram

The external size of –R option, –J option, –J1 option, –N2 option and –T option models is different from the standard model. See “6.

Options and Others” in Instruction Manual for more details.

from input, output, and FG.

Do not use the power supply in overcurrent conditions or in unspecified

input voltage ranges. Otherwise the internal components may be

damaged.

Parallel operation is not possible with this mode.

Sound noise may be heard from the power supply when used for

pulse load.

OTHERS

CASE SIZE/WEIGHT

41X97X109mm [1.61X3.82X4.29 inches] (Excluding terminal block and screw) (WXHXD) / 500g max

COOLING METHOD

Convection

WARRANTY WARRANTY

5 years (subject to the operating conditions)

AC IN 85 - 264V

DC OUT

RC(-R)

RECTIFIER

OVER VOLTAGE

PROTECTION

CURRENT

SENSING

NOISE

FILTER

INRUSH

CURRENT

LIMIT

RECTIFIER

AND

FILTER

FUSE

250V 3.15A

INVERTER

CONTROL

EXTERNAL

SOURCE

CONTROL

INVERTER

CURRENT

SENSING

RECTIFIER

AND

FILTER

BOOSTER

INDUCTOR

- Compact design (Depth: 109mm 4.29inches)

- High efficiency (88%typ PJA100F-24, AC230Vin, 100% load)

- Low power consumption (1.5W typ AC240Vin, no load at standard model)

- UL508 approved (Except option -J, -J1), and complies with SEMI F47 (see instruction manual 1.1)

- Various connection interface options (vertical terminal [-T], AMP connector [-J], [-J1])

SPECIFICATIONS
