A22NE-PD

Specifications

Certified Standard Ratings

• UL508 (File No. E76675), CSA C22.2 No.14

5 A at 125 VAC, 3 A at 250 VAC B300

•TÜV (EN60947-5-1) - Certified direct opening -

(EN60947-5-5)

AC-15 3 A at 125 VAC

DC-13 1 A at 30 VDC

• CCC (GB14048.5)

AC-15 3 A at 125 VAC

DC-13 1 A at 30 VDC

Applicable Standards

UL1059, UL486E

Note: Use a 10 A fuse type gI or gG that conforms to IEC60269 as a

short-circuit protection device. This fuse is not provided in the

main unit.

Certified Standards

Note: Only models with NC contacts have a direct opening

mechanism.

* UL-certification for CSA C22.2 No. 14 has been obtained.

Ratings

Contacts (Standard Load)

Note: 1. The above ratings were obtained by conducting tests under

the following conditions.

(1) Ambient temperature: 20

°±2°C

(2) Ambient humidity: 65

±5%

(3) Operating frequency: 20 operations/minute

2. Minimum applicable load: 1 mA at 5 VDC (Resistive load)

The operating range may vary depending on the usage

conditions and type of load.

LED Lamp (A22NZ-L-RC)

Certification

body

Standards

File No.

UL508, C22.2 No.14

E76675

TÜV SÜD

EN60947-5-1

(Certified direct opening),

EN60947-5-5

Consult your OMRON

representative for details.

CQC (CCC)

GB14048.5

Consult your OMRON

representative for details.

Rated

insulation

voltage (V)

Rated carry

current (A)

Rated

voltage

(V)

Rated current (A)

AC15

(Inductive

load)

AC12

(Resistive

load)

DC13

(Inductive

load)

DC12

(Resistive

load)

250

30 VAC

---

125 VAC

3 A

5 A

---

250 VAC

1.5 A

3 A

---

30 VDC

---

1 A

2 A

125 VDC

---

0.22 A

0.4 A

250 VDC

---

0.1 A

0.2 A

Rated voltage

Operating voltage

Current value

24 VAC/VDC

24 VAC/VDC ± 10%

Approx. 12 mA
