www.recom-power.com

REV.: 0/2023

ECO-1

DC/DC Converter

Description

The RSK-RUW series is a state-of-the-art isolated DC/DC converter that boasts an ultra-wide 8:1

input voltage range of 4.5-36 VDC. The RSK-RUW also includes ON/OFF control for added convenience

and precision. The device delivers high accuracy and tight line and load regulation, ensuring stable

performance even in challenging conditions. The RSK-RUW also includes continuous short circuit

protection and undervoltage lockout (UVLO) for added safety and security. This product is certified

according to IEC/EN/UL 62368-1, making it suitable for use in a variety of industrial applications. With

a maximum output power of 2W and the ability to operate at 0% minimum load, the RSK-RUW is very

versitile. The device also offers high efficiency, with a typical value of 88.5%. Finally, the RSK-RUW

offers basic grade isolation of 3kVDC/1min and an industrial operating temperature range of -40°C to

85°C without derating, making it ideal for use in demanding industrial environments.

Features

Regulated

Converters

• 8:1 wide input voltage range

• SIP8 package

• Continuous short circuit protection

• No minimum load required

• 3kVDC/1min basic isolation

• 88.5% typical efficiency

UL62368-1 certified

C22.2 No. 62368-1-19 certified

IEC/EN62368-1 certified

CB Report

E224736

C

O

M

CONVER

T

M

P

LIA

NT PRO

D

U

REACH

compliant

C

O

M

CONVER

T

M

P

LIA

NT PRO

D

U

RoHS 2+

compliant

10 from 10

RSK-RUW

2 Watt

SIP8

Single Output

Model Numbering

3kVDC Isolation

Output Voltage

RSK-2405SRUW/H3

Notes:

Note1: Efficiency is tested at nominal input and full load at +25°C ambient

Note2: Max Cap Load is tested at nominal input and full resistive load

Selection Guide

Part

Number

Input

Voltage Range

[VDC]

Output

Voltage

[VDC]

Output

Current

[mA]

Efficiency

typ. (1)

[%]

max. Capacitive

Load (2)

[µF]

RSK-2405SRUW/H3

4.5-36

5

400

88.5

2000

BASIC CHARACTERISTICS

Parameter

Condition

Min.

Typ.

Max.

Internal Input Filter

capacitors

Input Voltage Range

nom. VIN= 24VDC

4.5VDC

36VDC

Under Voltage Lockout (UVLO)

DC-DC ON

4VDC

4.3VDC

DC-DC OFF

3.3VDC

3.6VDC

Quiescent Current

20mA

Minimum Load

0%

ON/OFF CTRL

DC-DC ON

Open or VCTRL>1.5VDC

DC-DC OFF

Short to -VIN or <1.5VDC

Input Current of CTRL Pin

DC-DC ON

1mA

Standby Current

DC-DC OFF

3mA

6mA

Internal Operating Frequency

100kHz

400kHz

Output Ripple and Noise (3)

20MHz BW

VIN= 5VDC

50mVp-p

VIN= 24VDC

100mVp-p

continued on next page

Notes:

Note3: Measurements are made with a 0.1µF MLCC across output (low ESR)

Specifications (measured @ t

amb

= 25°C, nom. VIN, full load and after warm-up unless otherwise stated)
