SY88823V

Micrel, Inc.

M9999-110905

hbwhelp@micrel.com or (408) 955-1690

CC = 3.0V to 3.6V or 4.5V to 5.5V; TA = –40°C to +85°C; RLOAD = 50Ω to VCC; typical values at VCC = 3.3V, TA = 25°C

Symbol

Parameter

Condition

Min

Typ

Max

Units

PSRR

Power Supply Rejection Ratio

tr,tf

Output Rise/Fall Time

Note 8

120

(20% to 80%)

JITTER

Deterministic

Note 9

Random

5ps

RMS

Differential Input Voltage Swing

1800

mVPP

Differential Output Voltage Swing

3.3V, Note 8

700

800

950

mVPP

5V, Note 8

700

800

1020

mVPP

HYS

SD Hysteresis

Note 10

4.6

OFF

SD Release Time

0.1

0.5

µs

SD Assert Time

0.2

0.5

µs

SD Sensitivity Range

Note 11

mVPP

–3dB

–3dB Bandwidth

2.0

GHz

V(Diff)

Differential Voltage Gain

Single-Ended Small Signal-Gain

Notes:

8. Amplifier in limiting mode. Input is a 200MHz square wave, tr < 300ps.

9. Deterministic jitter measured using 2.488Gbps K28.5 pattern, VID = 10mVpp. Random jitter measured using 2.488Gbps K28.7 pattern, VID = 10mVpp.

10. Electrical signal.

11. This is the detectable range of input amplitudes that can de-assert SD. The input amplitude to assert SD is 2–8dB higher than the de-assert amplitude.

See “Typical Operating Characteristics” for graphs showing how to choose a particular RSDLVL or VSDLVL for a particular SD de-assert, and its

associated assert, amplitude. If increased SD sensitivity and hysteresis are required, an application note entitled “Notes on Sensitivity and Hysteresis

in Micrel Post Amplifiers” is available at http://www.micrel.com/product-info/app_hints+notes.shtml.

AC ELECTRICAL CHARACTERISTICS
