ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Input Voltage

VOUT=5~9V

VIN

30

V

VOUT=10~18V

35

V

VOUT=24V

40

V

Output Current

IOUT

100

mA

Power Dissipation

SOT-223

PD

750

mW

SOT-89

500

mW

SOT-25

240

mW

SOP-8

660

mW

TO-92/TO-92NL

625

mW

Junction Temperature

TJ

+150

°C

Operating Temperature (Note 2)

TOPR

-40 ~ +125

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. It is guarantee by design, not 100% be tested.



THERMAL DATA

PARAMETER

SYMBOL

RATING

UNIT

Junction to Ambient

SOT-223

θJA

133

°C/W

SOT-89

200

°C/W

SOT-25

416

°C/W

SOP-8

150

°C/W

TO-92/TO-92NL

160

°C/W

Junction to Case

SOT-223

θJC

15

°C/W

SOT-89

50

°C/W

SOT-25

130

°C/W

SOP-8

45

°C/W

TO-92/TO-92NL

83

°C/W
