SS22AF

THRU

SS220AF

SS22AF THRU SS220AF SCHOTTKY RECTIFIER

Note: 1. VR = 5V, TC = 25 C, fSIG = 1MHz

2. mounted on P.C. Board with 5.0mm2 copper pad areas.

Features

Circuit Diagram

Mechanical Data

Maximum Ratings and Electrical Characteristics @TA=25°C unless otherwise specified

Type Number

Symbol

SS

22AF

SS

23AF

SS

24AF

SS

245AF

SS

25AF

SS

26AF

SS

28AF

SS

210AF

SS

215AF

SS

220AF Units

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

VDC

20

30

40

45

50

60 80

100

150 200

V

RMS Reverse Voltage

VRMS

14

21

28

31

35

42 56

70

105 140

V

Average forward rectified output current

@TA = 90°C

IO

2

A

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave superimposed on

rated load (JEDEC Method)

IFSM

50

A

Forward Voltage (per element)

@IF =2.0A

VFM

0.55

0.7

0.85

0.92

V

Peak Reverse Current

@TA = 25°C

At Rated DC Blocking Voltage @TA = 100°C

IRM

0.1

10

0.05

5

mA

Typical Junction Capacitance(per leg) (Note 1)

CJ

28

pF

Typical Thermal Resistance (per leg) (Note 2)

RθJL

88

°C/W

Operating and Storage Temperature Range

TJ, TSTG

-55 to +150

°C



Case: SMAF, Molded plastic



Terminals: Plated leads solderable per MIL-STD-750,

Method 2026 guaranteed



Polarity: Color band denotes cathode end



Mounting Position: Any



Schottky Brrier Chip



Low Power Loss, High Efficiency



Ideally Suited for Automatic Assembly



Surge Overload Rating to 50A Peak



Plastic Case Material has UL Flammability Classification

Rating 94V-0



This is a Pb − Free Device



All SMC parts are traceable to the wafer

lot



Additional testing can be offered upon request

SMAF
