6HDD26PBY99R20X Datasheet(PDF) 1 Page - CONEC Elektronische Bauelemente GmbH |
|
|
|||||||||||||||||||||||||||||
6HDD26PBY99R20X Datasheet(HTML) 1 Page - CONEC Elektronische Bauelemente GmbH |
|
|
1 / 2 page  A A A A A A A A B B B B B B B B C C C C C C C C D D D D D D D D E E E E E E E E F F F F F F F F A A A A A A A A B B B B B B B B C C C C C C C C D D D D D D D D 6HDD26P Y99R20X CONEC ABC o dim. in mm R R R R date drawn d-old norm appd. tolerance material: title: dwg no: DIN- sh: part no: name date name description rev. scale: 15K1A1074 A3 1/2 D-SUB HD MALE 90° SEE NOTES Henneboel 11.07.12 11.07.12 Koch 26pos. SOLDER PIN ANGLED threaded insert, metal bracket, fixing plate 18K1A476/18K2A476 2:1 (5:1) 6HDD26P Y99R20X a Original 1 x b Ä4375 11.07.12 K.H. o NOTES: 1. FOR WAVESOLDERING ( SOLDER BATH TEMPERATURE 240°C FOR 5 SEC. / AND SOLDER PREHEAT 120°C FOR 120 SEC. ) 2. METALSHELLS: COPPER ALLOY; min. 315µin TIN over 40-80µin NICKEL 3. INSULATORS: PBT GF UL 94 V-0; BLACK 4. SIGNAL CONTACTS: COPPER ALLOY; PLATING (SEE PART NO.): PLEASE ADD C for 30µin HARD GOLD over min. 50µin NICKEL PLEASE ADD B for 20µin HARD GOLD over min. 50µin NICKEL PLEASE ADD A for GOLD FLASH over NICKEL (PREFERRED TYPE) 5. METAL BRACKETS: ZINC DIE CAST; 300µin COPPER/40-120µin NICKEL/ 120-200µin TIN 6. THREADED INSERTS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL 7. HEXLOCKING SCREWS: STAINLESS STEEL 8. FRAME: ZINC DIE CAST; NICKEL PLATED 9. FIXING PLATE: PBT GF UL 94 V-0; BLACK 10. O-RING: SILICON; BLUE 11. RUBBER GASKET: TPE 12. SEALING COMPOUND: PUR; BLUE 13. P.C.B. HOLE DRILLINGS AND RECOMMENDED PANEL CUT-OUT ON SHEET 2 14. RECOMMENDED TORQUE FOR MOUNTING SCREW 35Ncm (3.1 in.LB) / max.40Ncm (3.5 in.LB) 15. CONNECTOR IS PART MARKED: 6HDD26P Y99R20X CONEC ABC (see note 4) o o o 25,17 -0,05 0,2 + 8,26 -0,03 0,22 + 6,35 `0,3 O-RING AT ALL TIMES WATER RESISTANT CONNECTORS NOT IN USE SHOULD BE COVERED WITH A CONEC WATERRESISTANT CAP OR WATERTIGHT HOOD. SEE NOTE 15 SEALING COMPOUND RUBBER GASKET PLACED ON TOP SURFACE OF MALE INSULATOR FIXING PLATE 3,3 -0 0,5 + POS. 1 POS. 10 POS. 19 SEE NOTE 8 33,3 -0,1 0,15 + 47,7 -0 0,3 + 10° 4,8 SW 4-40 UNC METAL BRACKET 4-40 UNC Directive 2002/95/EC RoHS compliant o (see note 4) b |
