6HDF44PBY04R20X Datasheet(PDF) 1 Page - CONEC Elektronische Bauelemente GmbH |
|
|
|||||||||||||||||||||||||||||
6HDF44PBY04R20X Datasheet(HTML) 1 Page - CONEC Elektronische Bauelemente GmbH |
|
|
1 / 2 page  ( 5 : 1 ) A A A A A A A A B B B B B B B B C C C C C C C C D D D D D D D D E E E E E E E E F F F F F F F F A A A A A A A A B B B B B B B B C C C C C C C C D D D D D D D D 6HDF44PoY04R20X CONEC ABC dim. in mm R R R R date drawn d-old norm appd. tolerance material: title: dwg no: DIN- sh: part no: name date name description rev. scale: 15K1A1843 A3 1/2 D-SUB HD FILTER MALE 90° SEE NOTES Henneboel 14.01.16 14.01.16 Lehmenkühler 44pos. SOLDER PIN ANGLED thread insert,metal bracket,fixing-plate and hexl. screw 2:1 (5:1) 6HDF44P Y04R20X a Original FILTER IS TOTALLY GUARDED AGAINST HUMIDITY. WATER COULD PENETRATE INTO THE MATING AREA. AT ALL TIMES WATER RESISTANT CONNECTORS NOT IN USE SHOULD BE COVERED WITH A CONEC WATER RESISTANT CAP OR WATER TIGHT HOOD. 8,26 - 0,03 0,22 + 38,86 - 0,02 0,23 + 10° SEE NOTE 16 NOTES: 1. FOR WAVESOLDERING (SOLDER BATH TEMPERATURE 240°C FOR 5 SEC. AND SOLDER PREHEAT 100°C FOR 30 SEC.) 2. METALSHELLS: COPPER ALLOY; min. 315µin TIN over 40-80µin NICKEL 3. INSULATOR: HIGH TEMPERATURE PLASTIC UL 94 V-0; BLACK 4. CONTACTS: COPPER ALLOY; PLATING (SEE PART NO.:) o PLEASE ADD A for GOLD FLASH over NICKEL (PREFERRED TYPE) o PLEASE ADD B for 20µin HARD GOLD over min. 50µin NICKEL o PLEASE ADD C for 30µin HARD GOLD over min. 50µin NICKEL 5. METAL BRACKETS: ZINC DIE CAST; 300µin COPPER / 40-120min NICKEL / 120-200µin TIN 6. THREADED INSERTS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL 7 FRAME: ZINC DIE CAST;NICKEL PLATED 8. HEXLOCKING SCREWS: STAINLESS STEEL 9. FIXING-PLATE: PBT GF UL 94 V-0; BLACK 10. RUBBER-GASKET: TPE; BLACK 11. SEALING COMPOUND: PUR; BLUE 12. CAPACITANCE: 830pF `20% 13. DIELECTRIC WITHSTANDING VOLTAGE: 300 VDC 14. P.C.B. HOLE DRILLINGS AND RECOMMENDED PANEL CUT-OUT ON SHEET 2 15. RECOMMENDED TORQUE FOR MOUNTING SCREW 35Ncm ( 3.1 in.LB) / max. 40Ncm (3.5 in.LB) 16. CONNECTOR IS PART MARKED: 6HDF44PoY04R20X CONEC ABC (see note 4) 3,3 - 0 0,5 + 6,35 `0,3 FIXING-PLATE SEALING COMPOUND 61,4 - 0 0,3 + METAL BRACKET 4,8 SW 4-40 UNC SEE NOTE 7 47,04 `0,13 4-40 UNC RoHS compliant o (see note 4) RUBBER GASKET PLACED ON TOP SURFACE OF MALE INSULATOR 2,25 O-RING POS. 31 POS. 16 POS. 1 |
