4LS datasheet(73/115 Pages) OSRAM

73 / 115 page

Document Feedback

4LS

Datasheet

• PUBLIC

DS000542

• v3-01 • 2022-Nov-17

114

│ 72

9.1.20

Training Sequence 1 Line 2 Register (Address 0x13)

Figure 118:

TSQ1L2Reg

Address: 0x13

Default Value: 0xFF

Access: Read/Write

Bit

Bit Name

Default

Bit Description

7:0

Training sequence 1

11111111b

Defines the 8 MSBs for word A training

sequence sent over the LVDS driver of

Line 2 for FPGA synchronization

purposes.

9.1.21

Training Sequence 2 Line 2 Register (Address 0x14)

Figure 119:

TSQ2L2Reg

Address: 0x14

Default Value: 0xFF

Access: Read/Write

Bit

Bit Name

Default

Bit Description

7:0

Training sequence 2

11111111b

Defines the 8 MSBs for word B training

sequence sent over the LVDS driver of

Line 2 for FPGA synchronization

purposes.

9.1.22

Training Sequence 3 Line 2 Register (Address 0x15)

Figure 120:

TSQ3L2Reg

Address: 0x15

Default Value: 0xAA

Access: Read/Write

Bit

Bit Name

Default

Bit Description

7:0

Training sequence 3

10101010b

Defines the LSBs for word A and B

training sequence sent over the LVDS

driver of Line 2 for FPGA synchronization

purposes.
