3 / 4 page  DA100J Series SM Transformers for Digital Audio Data Transmission KMP_DA100JC_D01 Page 3 of 4 www.murata.com TAPE & REEL SPECIFICATIONS REEL OUTLINE DIMENSIONS TAPE OUTLINE DIMENSIONS 1.20 (30.4) Max. 0.94-1.08 (23.9-27.4) 0.53 (13.50) 0.50 (12.80) 0.059 (1.50) Min. 2.36 (60) Min. 0.80 (20.20) Min. 3.9 (100) Min. Leader section 15.7 (400) Min. Goods enclosure section Trailer section 6.3 (160) Min. Ø15.039 (382) Max. Ø Ø * 0.96 (24.4) 1.04 (26.4) Unless otherwise stated all dimensions in inches (mm) ±0.01(0.25). * Includes flange distortion at outer edge. Measured at hub. 0.024 (0.60) Max. 0.283 (7.20) 0.369 (9.37) Direction of unreeling 0.069 (1.75) 0.157 (4.00) 0.079 (2.00) 0.472 (12.00) Cover tape 0.059 (1.50 ) +0.004 -0.000 +0.10 -0.00 Unless otherwise stated all dimensions in inches (mm) ±0.01(0.25). |
|
|
