Silicon NPN Power Transistor

2SC5808

www.iscsemi.com

2

ELECTRICAL CHARACTERISTICS （TC=25℃ unless otherwise specified）

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP.

MAX

UNIT

VCE(sat)

Collector-Emitter Saturation

Voltage

IC= 1.2A; IB= 0.24A

--

--

0.8

V

VBE(sat)

Base-Emitter Saturation Voltage

IC= 1.2A; IB= 0.24A

--

--

1.5

V

V(BR)CBO

Collector-Base Breakdown Voltage

IC= 1mA; IB= 0

700

--

--

V

V(BR)CEO

Collector-Emitter Breakdown

Voltage

IC= 4mA; IB= 0

400

--

--

V

V(BR)EBO

Emitter-Base Breakdown Voltage

IE= 1mA; IC= 0

8

--

--

V

ICBO

Collector Cutoff Current

VCB= 400V; IE= 0

--

--

10

uA

IEBO

Emitter Cutoff Current

VEB= 5V; IC= 0

--

--

10

uA

hFE1

DC Current Gain

IC= 0.3A; VCE= 5V

20

--

50

hFE2

DC Current Gain

IC= 1.2A; VCE= 5V

10

--

--

hFE3

DC Current Gain

IC= 1mA; VCE= 5V

10

--

--
