PLL500-17

Low Phase Noise VCXO (17MHz to 36MHz)

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/08/06 Page 5

SOIC 8L

SOT23-6 L

Dimension in MM

Symbol

Min.

Max.

A

1.35

1.75

A1

0.10

0.25

A2

1.25

1.50

B

0.33

0.53

C

0.19

0.27

D

4.80

5.00

E

3.80

4.00

H

5.80

6.20

L

0.40

0.89

e

1.27 BSC

Dimension in MM

Symbol

Min.

Max.

A

1.05

1.35

A1

0.05

0.15

A2

1.00

1.20

b

0.30

0.50

c

0.08

0.20

D

2.80

3.00

E

1.50

1.70

H

2.60

3.0

L

0.35

0.55

e

0.95 BSC

C

L

A2

E

H

D

A1

e

b

A

C

L

A2

E

H

D

A1

e

b

A

Pin1 Dot
