13 / 28 page ![]() © 2007 Microchip Technology Inc. DS21290D-page 13 MCP3201 FIGURE 4-1: Analog Input Model. FIGURE 4-2: Maximum Clock Frequency vs. Input Resistance (R S) to maintain less than a 0.1 LSB deviation in INL from nominal conditions. C PIN VA R SS CHx 7pF V T = 0.6V V T = 0.6V I LEAKAGE Sampling Switch SS R S = 1 kΩ C SAMPLE = DAC capacitance V SS V DD = 20 pF ±1 nA LEGEND VA = Signal Source Rss = Source Impedance CHX = Input Channel Pad C PIN = Input Pin Capacitance V T = Threshold Voltage I LEAKAGE = Leakage Current At The Pin Due To Various Junctions SS = Sampling Switch Rs = Sampling Switch Resistor C SAMPLE = Sample/hold Capacitance 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 100 1000 10000 Input Resistance (Ohms) VDD = VREF = 5V VDD = VREF = 2.7V |
|
