R
版本：
202005I
1/9
双向晶闸管
TRIACS
3FT8C/U/V/F1
主要参数
MAIN CHARACTERISTICS
封装 Package
序号
Pin
引线名称
Description
1
主电极 1
MT1
2
主电极 2
MT2
3
门极
G
IT(RMS)
8A
VDRM
800V
IGT
10mA
用途
APPLICATIONS
 交流开关
 AC switching
 相位控制
 Phase control
产品特性
FEATURES
 玻璃钝化芯片，
高 可 靠 性 和 一
致性
 Glass-passivated mesa
chip for high reliability
and uniform
 低通态电流和高
浪涌电流能力
 Low on-state voltage and
High ITSM
 环保 RoHS 产品
 RoHS products
订货信息 ORDER MESSAGES
订货型号 Order codes
印记
Marking
封装
Package
有卤-袋装
无卤-袋装
有卤-条管
无卤-条管
3FT8C
TO-220C
Halogen-Bag
Halogen-Free-Bag
Halogen-Tube
Halogen-Free-
Tube
3FT8C-CA-C
3FT8C-CA-CR
3FT8C-CA-B
3FT8C-CA-BR
有卤-编带
无卤-编带
有卤-袋装
无卤-袋装
3FT8U
DPAK
Halogen-Reel
Halogen-Free-
Reel
Halogen-Bag
Halogen-Free-Ba
g
3FT8U-R-A
3FT8U-R-AR
3FT8U-R-C
3FT8U-R-CR
有卤-袋装
无卤-袋装
有卤-条管
无卤-条管
3FT8V
IPAK
Halogen-Bag
Halogen-Free-Bag
Halogen-Tube
Halogen-Free-
Tube
3FT8V-V-C
3FT8V-V-CR
3FT8V-V-B
3FT8V-V-BR
TO-220C
DPAK
IPAK
TO-220MF-K1
