ST7LITE49M
Electrical characteristics
159/188
Static and dynamic latch-up
●
LU: 3 complementary static tests are required on 6 parts to assess the latch-up
performance. A supply overvoltage (applied to each power supply pin) and a current
injection (applied to each input, output and configurable I/O pin) are performed on each
sample. This test conforms to the EIA/JESD 78 IC latch-up standard. For more details,
refer to the application note AN1181.
Table 88.
Electrical sensitivities
Symbol
Parameter
Conditions
Class
LU
Static latch-up class
TA = +125 °C
A
DLU
Dynamic latch-up class
VDD = 5.5 V, fOSC = 4 MHz,
TA = +125 °C
A
