background image
版本：202308G
1/10
N 沟道增强型场效应晶体管
N-CHANNEL MOSFET
JCS60N10I
-
订 货 型 号 Order codes
印
记
Marking
封
装
Package
有卤-条管
Halogen-Tube
无卤-条管
Halogen-Free-Tube
有卤-编带
Halogen-Reel
无卤-编带
Halogen-Free-Reel
JCS60N10I-C-B
JCS60N10I-C-BR
N/A
N/A
JCS60N10
TO-220C
JCS60N10I-R-B
JCS60N10I-R-BR
JCS60N10I-R-A
JCS60N10I-R-AR
JCS60N10
DPAK
JCS60N10I-S-B
JCS60N10I-S-BR
JCS60N10I-S-A
JCS60N10I-S-AR
JCS60N10
TO-263
JCS60N10I-B-B
JCS60N10I-B-BR
N/A
N/A
JCS60N10
TO-262
封装 Package
主要参数
MAIN
CHARACTERISTICS
ID
60A
VDSS
100V
Rdson-max
(@Vgs=10V）
16mΩ
Qg-typ
51nC
用途
 高功率 DC/DC 转换与
功率开关
 直流电机控制
 汽车应用
 不间断电源
APPLICATIONS
 High power DC/DC
converters and switch
mode power supplies
 DC motor control
 Automotive applications
 Uninterruptible power
supply
产品特性
低栅极电荷
低 Rdson
开关速度快
产品全部经过雪崩测试
高抗 dv/dt 能力
RoHS 产品
FEATURES
Low gate charge
Low Rdson
Fast switching
100% avalanche tested
Improved dv/dt capability
RoHS product
订货信息 ORDER MESSAGE
