DDP-SJS-NP2-1-I3

• DDP-SJS-N1

• DDP-SJS-N2

• DDP-SJS-P1

• DDP-SJS-P2

AlInGaP/

Pure Green, 560nm

120

28.5 - 71.5

28.5 - 35.5

35.5 - 45.0

45.0 - 56.0

56.0 - 71.5

AlInGaP : DDP-SJS-NP2-1-I3

Semiconductors

Innovating Illumination

Part Ordering

Number

Chip Technology

/ Color

Viewing

Angle˚

Luminous Intensity @

IF = 30mA IV (mcd)

NOTE

1. All part number above comes in a quantity of 2000 units per reel.

2. Luminous intensity is measured with an accuracy of ± 11%.

3. Wavelength binning is carried for all units as per the wavelength-binning table. Only one wavelength group is allowed for each reel.

Vf @ If = 30mA

Forward voltage are measured using a current pulse of 1 ms and with an accuracy of ± 0.1 V.

Electrical Characteristics at Ta=25˚C

Max. (V)

Vr @ Ir = 10uA

Min. (V)

Part Number

DDP-SJS

2.4

12

Typ. (V)

1.9

Group

Wavelength Grouping.

Color

DDP; Pure Green

Full

552.5 - 564.5

Dominant wavelength is measured with an accuracy of ± 1 nm.

Wavelength distribution(nm)

W

552.5 - 555.5

X

555.5 - 558.5

Y

558.5 - 561.5

Z

561.5 - 564.5
