InGaN White : DDW-xJD

Semiconductors

Innovating Illumination

28/09/2005 V2.0

3

Forward Voltage (V)

Vf Bining (Optional)

Vf Bin @ 20 mA

0A

00

01

02

2.75 ... 3.05

3.05 ... 3.35

3.35 ... 3.65

3.65 ... 3.95

Forward Voltage, Vf is measured with an accuracy of ± 0.1 V.

Vf @ If = 20 mA

3.2

5.0

Forward Voltage, Vf is measured with an accuracy of ± 0.1 V.

Part Number

Min. (V)

Typ. (V)

Max. (V)

Min. (V)

DDW-xJD

2.9

3.8

Unit

Absolute Maximum Ratings

Maximum Value

DC forward current

Peak pulse current; (tp ≤ 10µs, Duty cycle = 0.005)

Reverse Voltage

ESD Threshold (HBM)

LED juction temperature

Operating temperature

Storage temperature

Power dissipation (at room temperature)

20

200

5

2000

125

-40 … +100

-40 … +100

85

mA

mA

V

V

˚C

˚C

˚C

mW

Please consult sales and marketing for special part number to incorporate Vf bining.
