7060X and 7260X Series | Technical Speci cations

Speci cations

Switch Model

7060CX2-32S

7060SX2-48YC6

7060CX-32S

7260CX-64 2

7260QX-64 2

Ports

32 x QSFP100

2x SFP+

48 x SFP25

6x QSFP100

32 x QSFP100

2x SFP+

64x QSFP100

2x SFP+

64x QSFP+

2x SFP+

Max 100GbE Ports

32

6

32

64

0

Max 40GbE Ports

32

6

32

64

64

Max 25GbE Ports

128

(4x25G)

72

(48xSFP25 & 6 4x25G)

128

(4x25G)

256

(4x25G)

0

Max 10GbE Ports

130

(32 4x10G & 2xSFP+)

72

(48xSFP+ & 6 4x10G)

130

(32 4x10G & 2xSFP+)

258

(64 4x10 & 2xSFP+)

2

Max 1GbE Ports

2

48

2

2

2

Throughput

6.4 Tbps

3.6 Tbps

6.4 Tbps

12.8Tbps

5.12Tbps

Packets/Second

3.3 Bpps

2.7 Bpps

3.3 Bpps

9.52 Bpps

3.3 Bpps

Latency

450ns

450ns

450ns

550 to 1500ns

550ns

CPU

Multi-Core x86

Multi-Core x86

Multi-Core x86

Dual-Core i7 x86

Multi-Core x86

System Memory

8 Gigabytes

8 Gigabytes

4 Gigabytes

8 Gigabytes

4 Gigabytes

Flash Storage

Memory

4 Gigabytes

4 Gigabytes

4 Gigabytes

4 Gigabytes

4 Gigabytes

Packet Bu er

Memory

22MB (Dynamic

Buffer Allocation)

22MB (Dynamic

Buffer Allocation)

16MB (Dynamic

Buffer Allocation)

64MB (Dynamic

Buffer Allocation)

16MB (Dynamic

Buffer Allocation)

100/1000 Mgmt

Ports

1

1

1

1

1

RS-232 Serial Ports

1 (RJ-45)

1 (RJ-45)

1 (RJ-45)

1 (RJ-45)

1 (RJ-45)

USB Ports

1

1

1

1

1

Hot-swap Power

Supplies

2 (1+1 redundant)

2 (1+1 redundant)

2 (1+1 redundant)

2 (1+1 redundant)

2 (1+1 redundant)

Hot-swappable Fans

4 (N+1 redundant)

4 (N+1 redundant)

4 (N+1 redundant)

4 (N+1 redundant)

4 (N+1 redundant)

Reversible Air ow

Yes

Yes

Yes

Yes

Yes

Typical/Max Power

Draw*

187W / 333W

240W / 385W

187W / 333W

1672W / 2090W

315W / 800W

Size (WxHxD)

19 x 1.75 x 16 inches

(48.3x 4.4x 40.64cm)

19 x 1.75 x 16 inches

(48.3x 4.4x 40.64cm)

19 x 1.75 x 16 inches

(48.3x 4.4x 40.64cm)

19 x 3.5 x 18 inches

(48.3 x 8.8 x45.7 cm)

19 x 3.5 x 18 inches

(48.3 x 8.8 x45.7 cm)

Weight

21lbs (9.5kg)

19.4lbs (8.8kg)

21lbs (9.5kg)

44.1lbs (20.0kg)

35.5 lbs (16.1kg)

Fan Tray

FAN-7000

FAN-7000H

FAN-7000

FAN-7002H

FAN-7002

Power Supplies

500W AC

500W DC

500W AC

500W DC

500W AC

500W DC

1900W AC

1900W DC

1100W AC

1900W DC

EOS Feature

Licenses

Group 2

Group 2

Group 2

Group 3

Group 2

* Typical power consumption measured at 25C ambient with 50% load

Note: 1.Performance rated over operation with average packets larger than 200 bytes.

Note 2. Product is subject to an end of sales notice
