Chassis

DCS-7368-CH

Supervisor slots

1

Linecard Slots

8

Power Supply Slots *

4 (N+N Redundant)

Fan Modules

5 (N+1 Redundant)

Size (HxWxD) - excluding

ejectors and handles

7” x 17.4” x 22”

(17.9 x 44.2 x 55.9cm)

Rack Space

4RU

Weight (Chassis only)

30 lbs (13.6 kg)

Weight (Fully con gured system)

85 lbs (38.6 kg)

Typical / Max Power

810 W 1 / 1526 W 1

Power Supplies

PWR-1900AC-F/R

PWR-1900-DC-F/R

Reversible Air ow Option

25/100G Only

Fan Tray

FAN-7002H-F/R

EOS Feature Licenses

LIC-FIX-3

Minimum EOS

EOS 4.22.0

7368X4 Series | Technical Speci cations

Supervisor Module

DCS-7368-SUP

DCS-7368-SUP-D

CPU

Multi-Core x86

System Memory

32 Gigabytes

Flash Storage Memory

8 Gigabytes

10/100/1000 Mgmt Ports

1

1G SFP Mgmt Port (SX, LX)

1

RS-232 Serial Ports

1 (RJ-45)

USB Ports

1

SSD Storage

30 GB

256 GB

Typical/Max Power Draw*

30 W / 48 W

30 W / 48 W

Size (HxWxD)

4.0” x 1.0” x 17.0”

(10.2 x 2.43 x 43.2cm)

Weight

2.5 lbs (1.14kg)

2.5 lbs (1.14kg)

Minimum EOS

EOS 4.22.0

1. System con guration: 1 x Sup, 1 x Switch Card, 8 x 16C line cards, 5 x fans, 2 x power supplies

2. Power excluding optics or cables, add power rating for optics to determine typical budget

3. Maximum power measured with 2.5W optics on all ports, adjust as appropriate for lower power optics

4. Maximum power measured with 4.5W optics on all ports, adjust as appropriate for lower power optics

5. Maximum power measured with 20W optics on all ports, adjust as appropriate for lower power optics

* If the system is populated with 2 or fewer I/O modules, it is recommended to not operate all the 4 PSU slots

I/O Modules

DCS-7368-16S

DCS-7368-16C

DCS-7358-16C

DCS-7368-4D

DCS-7368-4P

Ports

16 x SFP28

16 x QSFP28

16 x QSFP28

4 x QSFP-DD

4 x OSFP

Max 400GbE Ports

—

—

—

4

4

Max 200GbE Ports

—

8

8

8

8

Max 100GbE Ports

—

16

16

16

16

Max 25GbE Ports

16

16

16

—

—

Max 10GbE Ports

16

16

16

—

—

Typical/Max Power

Draw

36 W 2/ 88 W 3

83 W 2 / 140 W 4

83 W 2 / 140 W 4

72 W 2 / 140 W 5

72 W 2 / 140 W 5

Size (HxWxD)

6.7” x 1.7” x 9.5”

(17 x 4.4 x 24.2 cm)

6.7” x 1.7” x 9.5”

(17 x 4.4 x 24.2 cm)

6.7” x 1.7” x 9.5”

(17 x 4.4 x 24.2 cm)

6.7” x 1.7” x 9.5”

(17 x 4.4 x 24.2 cm)

6.7” x 1.7” x 9.5”

(17 x 4.4 x 24.2 cm)

Weight

2.56 lbs (1.16 kg)

3.1 lbs (1.41 kg)

3.1 lbs (1.41 kg)

2.7 lbs (1.23 kg)

2.7 lbs (1.23 kg)

Chassis Support

DCS-7368-CH

Air ow Option

Front to Rear / Rear to Front

Front to Rear Only

Minimum EOS

4.25.0

4.22.0

4.28.0

4.24.1

4.24.1
