SDO

CKSEL

SDO

TSTPA7

bd4rtd

120 DVDD

P DVDD

121 MTR_SEL

MTR_SEL

MTRS_EL

MTR_SEL

bd4rtd

122 MPU_SEL

MPU_SEL

MPUS_EL

bd4rtd

123 GPIO1

I/O GPIO1

I/O bd4rt

124 GPIO2

I/O GPIO2

I/O bd4rt

125 GPIO3

I/O GPIO3

I/O WMSEL/GPIO3 I/O GPIO3

I/O GPIO3

I/O bd4rt

126 GPIO4

I/O GPIO4

I/O RLCSEL/GPIO4 I/O GPIO4

I/O GPIO4

I/O bd4rt

127 TSTSEL0

TSTSEL0

bd4rtd

128 TSTSEL1

TSTSEL1

bd4rtd

NOTE:

In TCD2950D CCD:

Pin No : Pin Name

NORMAL

FAST

CCD_CK1X Clock 1

Clock

CCD_CK2X Clock 2

Clock

RGB_SEL0 Clock 2

Clock

In Mode 6 (SC TEST) :

Pin No : MPU_SEL = 0

MPU_SEL = 1

GPIO5

DMAD0

GPIO6

DMAD1

GPIO7

DMAD2

GPIO8

DMAD3

GPIO9

DMAD4

GPIO10

DMAD5

GPIO11

DMAD6

GPIO12

DMAD7

125

GPIO3

(WMSEL)

126

GPIO4

(RLCSEL)

In Mod 1,2,5,9

If Input clock = 12MHZ

If CKSEL = 0 => Scanner controller run 24MHZ

If CKSEL = 1 => Scanner controller run 32MHZ

In Mode 3:

If MPUCKOE = 1, MPUCLK = (Input clock frequency)/2

If CKSEL = 1 => Scanner controller run (Input clock frequency) /2

If CKSEL = 0 => Scanner controller run (Input clock frequency)

If MPUCKOE = 0, MPUCLK = 0

In Mode 4:

Scanner controller run (Input clock frequency)

5.2

Pin Descriptions :

MPU or DMA/EPP Interface

HSLCTIN(MPU_ALE )

EPP nAStrb or MPU ALE

HI_INIT(MPU_CS)

EPP nINIT or MPU Chip select

HAFXTIN(MPU_RD)

EPP nDStrb or MPU Read

HSTBIN(MPU_WR)

EPP nWrite or MPU Write
