ADL5387ACPZ-R71 Datasheet(PDF) 22 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5387ACPZ-R71 Datasheet(HTML) 22 Page - Analog Devices |
|
|
22 / 28 page  ADL5387 Rev. 0 | Page 22 of 28 R&S FSEA30 SPECTRUM ANALYZER HP 6235A POWER SUPPLY AGILENT 8665B SIGNAL GENERATOR LOW-PASS FILTER R&S SMT03 SIGNAL GENERATOR ADL5387 CHAR BOARD RF LO Q I GND VPOS 6dB PAD R1 50Ω BAND-PASS CAVITY FILTER BAND-PASS TUNABLE FILTER BAND-REJECT TUNABLE FILTER HP87405 LOW NOISE PREAMP Figure 61. Measurement Setup for Noise Figure in the Presence of a Blocker R&S FSEA30 SPECTRUM ANALYZER HP 8508A VECTOR VOLTMETER R&S SMT-06 AGILENT E3631 PWER SUPPLY AGILENT E8257D SIGNAL GENERATOR PC CONTROLLER R&S SMT-06 IEEE IEEE ADL5387 CHAR BOARD RF LO Q I GND VPOS 6dB PAD 6dB PAD SWITCH MATRIX RF AMPLIFIER VP GND OUT IN 3dB PAD 3dB PAD 3dB PAD 3dB PAD RF RF AGILENT 11636A RF INPUT Figure 62. General ADL5387 Characterization Setup |
|
