background image

Control Switches
Push Buttons
Illuminated
Push Buttons Pilot Lamps
Selector
Switches
Emergency
Stops
Double Push
Buttons
Buzzer
Model
MC2-P
MC2-LP
MC2-PI
MC2-S
MC2-E
MC2-2P
MC2-B-D
Life
Mechanical
50,000 times (0 times/min)
Rated
Voltage
AC/DC 1~0V
Electrical
100,000 times (0 times/min)
Current
60mA
Sound
Level
85dB @ 0.1m
75dB @ 1m
Protection Degree
IP5
IP50
IP40
Initial Contact Resistance
20MΩ maximum
Insulation Resistance
Min.100MΩ
Min.50MΩ
Operation Frequency
Max. 0 times/min
~ times/sec
Impact
Endurance
Min. 500m/s
²
No movement
Min. 100m/s
²
Vibration
10~55Hz with mm pick to pick
Operating Temperature: -15~40
°C
Operating Humidity: 45~85%RH
Storage Temperature: -40~70
°C
Model
NO
Contact
MC22-UA
NC
Contact
MC22-UB
Appearance
NO
NC
Contact
Capacity
110 VAC 10A / 0 VAC 5A
Approval
Contact Blocks
Model
DC/AC
LED
MC22-UA
AC
LED
MC22-UB
Appearance
100V~4mA / 220V~10mA
Operating
Voltage
DC/AC 1~0V
AC 110~0V
Current
Consumption
4~10mA
4~10mA
LED Life
50,000 hours
Approval
LEDs
Ø22 Push Button Mounting Hole Layout
& Panel Cutout
Specifications
Buzzers
Selectable Continuous and Intermittent Sound
LED Illumination
AC/DC 12~30V rated
•
•
•
MC2-B-D
