1 / 2 page  Schottky Rectifier Diode DF20PC3M www.iscsemi.com 1 FEATURES · Super Low VF= 0.4V · High Current Capacity with Small Package · SMD APPLICATIONS · DC OR Output · DC/DC Converter · CMobile Telephone, Personal Computer ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VRRM VRWM VR Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage 30 V IF(AV) Average Rectified Forward Current 10×2 A IFSM Non-repetitive Peak Surge Current (50Hz sine, I cycle) 200 A TJ Max. Junction Temperature 150 ℃ Tstg Storage Temperature Range -55~150 ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER MAX UNIT Rth j-c Thermal Resistance,Junction to Case 1.6 ℃ /W 2 2 3 1 |
