DD171N..K..-A Datasheet(PDF) 1 Page - Infineon Technologies AG |
|
|
|||||||||||||||||||||||||||||
DD171N..K..-A Datasheet(HTML) 1 Page - Infineon Technologies AG |
|
|
1 / 9 page  N Netz-Dioden-Modul Rectifier Diode Module Datenblatt / Data sheet DD171N IFBIP D AEC / 2016-01-28, A.Glunz A 13/11 1/9 Seite/page Kenndaten Elektrische Eigenschaften Thermische Eigenschaften Elektrische Eigenschaften / Electrical properties Höchstzulässige Werte / Maximum rated values DD171N DD171N..K..-A DD171N..K..-K ND171N Periodische Spitzensperrspannung repetitive peak reverse voltages Tvj = -40°C... Tvj max VRRM 1200 1600 1400 1800 V V Stoßspitzensperrspannung non-repetitive peak reverse voltage Tvj = +25°C... Tvj max VRSM 1300 1700 1500 1900 V V Durchlaßstrom-Grenzeffektivwert maximum RMS on-state current IFRMSM 270 A Dauergrenzstrom average on-state current TC = 100°C IFAVM 171 A Stoßstrom-Grenzwert surge current Tvj = 25 °C, tP = 10 ms Tvj = Tvj max, tP = 10 ms IFSM 6.600 5.600 A A Grenzlastintegral I²t-value Tvj = 25 °C, tP = 10 ms Tvj = Tvj max, tP = 10 ms I²t 218.000 157.000 A²s A²s Charakteristische Werte / Characteristic values Durchlaßspannung on-state voltage Tvj = Tvj max , iF = 500 A vF max. 1,26 V Schleusenspannung threshold voltage Tvj = Tvj max V(TO) 0,75 V Ersatzwiderstand slope resistance Tvj = Tvj max rT 0,8 mΩ Sperrstrom reverse current Tvj = Tvj max , vR = VRRM iR max. 20 mA Isolations-Prüfspannung insulation test voltage RMS, f = 50 Hz, t = 1 sec RMS, f = 50 Hz, t = 1 min VISOL 3,0 2,5 kV kV Thermische Eigenschaften / Thermal properties Innerer Wärmewiderstand thermal resistance, junction to case pro Modul / per Module, Θ = 180° sin pro Zweig / per arm, Θ = 180° sin pro Modul / per Module, DC pro Zweig / per arm, DC RthJC max. max. max. max. 0,130 0,260 0,126 0,252 °C/W °C/W °C/W °C/W Übergangs-Wärmewiderstand thermal resistance, case to heatsink pro Modul / per Module pro Zweig / per arm RthCH max. max. 0,03 0,06 °C/W °C/W Höchstzulässige Sperrschichttemperatur maximum junction temperature Tvj max 150 °C Betriebstemperatur operating temperature Tc op - 40...+150 °C Lagertemperatur storage temperature Tstg - 40...+150 °C prepared by: A.Glunz date of publication: 2016-01-28 approved by: M.Leifeld revision: 3.1 |
