2 / 3 page  Schottky Barrier Rectifier PBYR4045WT www.iscsemi.com 2 ELECTRICAL CHARACTERISTICS SYMBOL PARAMETER CONDITIONS MAX UNIT VF Maximum Instantaneous Forward Voltage IF= 20A ; TC= 25℃ 0.6 V IF= 20A ; TC= 125℃ 0.58 IF= 40A ; TC= 25℃ 0.76 IF= 40A ; TC= 125℃ 0.75 IR Maximum Instantaneous Reverse Current Rated DC Voltage, TC= 25℃ 2.5 mA Rated DC Voltage, TC= 100℃ 70 PACKAGE OUTLINE (UNIT: mm) |
|
|
