1 / 3 page

KAM05CT70G106KH Datasheet

(0402 4 V X7T 10uF ±10%)

Item

Unit

Spec.

Conditions

Capacitance

uF

9 to 11

@ 1 kHz, 0.5 Vrms

DF

%

12.5 max.

@ 1 kHz, 0.5 Vrms

IR

MΩ

5 min.

@ 4 Vdc, t = 60 s

millimetres

inches

L

1 ± 0.2

0.039 ± 0.008

W

0.5 ± 0.2

0.02 ± 0.008

T max.

0.7

0.028

t

0.25 ± 0.1

0.01 ± 0.004

AEC-Q200

Cap.Change [%] vs AC Voltage [VAC]

|Z| & ESR [Ohm] vs Frequency [Hz]

Phase Angle [°] vs Frequency [Hz]

Cap.Change [%] vs DC Voltage [VDC]

S21 [dB] (50Ω, shunt) vs Freq. [Hz]

To download data and

simulation models visit:

Basic Specifications

Dimensions

Cap.Change [%] vs Temperature [°C]

-55°C to +125°C

X7T

Yes

Operating Temperature

Dielectric

Product Level

RoHS Compliant

Electrical Characteristics

Termination

Sn

1E-3

1E-2

1E-1

1E+0

1E+1

1E+2

1E+3

1E+4

1E+5

1E+6

1E+7

1E+8

1E+9 1E+10

ESR

|Z|

Fres = 3.34E+6 Hz ~ ESR = 8.4E-3

Ω

-80

-70

-60

-50

-40

-30

-20

-10

0

1E+2 1E+3 1E+4 1E+5 1E+6 1E+7 1E+8 1E+9 1E+10

-135

-90

-45

0

45

90

1E+2 1E+3 1E+4 1E+5 1E+6 1E+7 1E+8 1E+9 1E+10

-80

-70

-60

-50

-40

-30

-20

-10

0

1

2

3

4

-35

-30

-25

-20

-15

-10

-5

0

5

10

-55

-25

5

35

65

95

125

1 kHz, 0.1 Vrms

-30

-25

-20

-15

-10

-5

0

5

0

0.2

0.4

0.6

0.8

1

1 kHz

[Hz]

[VAC]

[VDC]

[°C]

Updated: 07.02.2023.

Page: 1 of 3.
