JRR200 Route Reflector

Cloud-Based Route Reflector Design

With the growing complexities of the cloud and dependencies

on multicloud, the JRR200 offers an effective solution for

solving the best path selection process for cloud-based

route reflectors. The JRR200 can be run as a pre-integrated

application in any data center to assure the best possible

availability, scale, and routing performance.

Route Reflector in a Clos Fabric

The JRR200 plays a key architectural role in data center

networks where large numbers of connections across large

numbers of ports are managed by multiple switches. In this

nonblocking environment, the JRR200 can be hosted in the

spine node to interconnect leaf nodes to create a highly

available environment.

Figure 3: Cloud-based route reflector design

iBGP

Regional

Network 1

Regional

Network 2

Backbone

Data Center

Cloud

JRR 1

Region 1

Client 1

Client 2

Client 3

JRR 2

Region 2

JRR 2 selects path

based on R1 view

JRR 2 selects path

based on R2 view

iBGP

GRE, IGP

Figure 4: Route reflector in a Clos design

JRR200

Spine

Leaf
