Multi-layer Chip Diplexer

ADID-R-0004

1.0 x 0.5 x 0.4 mm

RoHS Compliant

Request Samples

Check Inventory

5101 Hidden Creek Ln Spicewood TX 78669

Phone: 512-371-6159 | Fax: 512-351-8858

REVISED: 02-19-24

For terms and conditions of sales, please visit:

www.abracon.com

Product Image

 LTCC diplexer supporting 2400~2500 / 5150~7125 MHz

 Small Form Factor 1.0 x 0.5 x 0.4 mm

 Low Insertion Loss 0.5 dB

 VSWR as low as 1.2

 RoHS Compliant

 Wi-Fi 6/6E Standards

 Wi-Fi Speakers and Sound Bars

 Video Streaming and Network Cameras

 VR Head Mount Displays

 Car Infotainment Systems

 Broadband Gateways
