ABRACON IS

ISO9001-2015

CERTIFIED

Hidden Creek Ln Spicewood TX 78669

5101

Phone: 512-371-6159 | Fax: 512-351-8858

REVISED: 11-26-24

For terms and conditions of sales, please visit:

www.abracon.com

Wi-Fi 6/6E/7 LTCC RF Diplexer

ADID-R-0013

1.6 x 0.8 x 0.6 mm

RoHS Compliant

Request Samples

Check Inventory

Product Image

• Supporting 2400~2500 / 5150~7150 MHz Simultaneously

• Small Form Factor 1.6 x 0.8 x 0.6 mm

• Low Insertion Loss 0.5 dB

• High Isolation Between Bands

• Temperature Stability Across Wide Temperature Bands

• High-Power Handling up to 3W

• RoHS Compliant

• Wi-Fi Modules

• AR/VR Headsets

• Wi-Fi Access Point and Mesh Wi-Fi Systems

• Smart Plugs, Lights, and Doorbells

• Smart TVs and Streaming Devices

• Laptops and PCs

Applications

Features
