Data Sheet

ADRF5703

ABSOLUTE MAXIMUM RATINGS

analog.com

Rev. 0 | 7 of 19

ELECTROSTATIC DISCHARGE (ESD) RATINGS

The following ESD information is provided for handling of ESD-sen-

sitive devices in an ESD protected area only.

Human body model (HBM) per ANSI/ESDA/JEDEC JS-001.

Charged device model (CDM) per ANSI/ESDA/JEDEC JS-002.

ESD Ratings for ADRF5703

Table 6. ADRF5703, 24-Terminal LGA

ESD Model

Withstand Threshold (V)

Class

HBM

ATTIN Pin and ATTOUT Pin

1500

Supply and Control Pins

3000

CDM

500

C2A

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Charged

devices and circuit boards can discharge without detection.

Although this product features patented or proprietary protec-

tion circuitry, damage may occur on devices subjected to high

energy ESD. Therefore, proper ESD precautions should be

taken to avoid performance degradation or loss of functionality.
