Feature

Value

CE marking (see declaration of conformity)

As per EU EMC directive

As per EU low voltage directive

As per EU RoHS directive

UKCA marking (see declaration of conformity)

To UK instructions for EMC

To UK RoHS instructions

To UK instructions for electrical equipment

Certificate issuing authority

TÜV 968/INS 464.00/24

UL E342973

Nominal operating voltage DC

680 V

Type of winding switch

Star inside

Number of pole pairs

5

Stall torque

1.24 Nm

Nominal torque

1.1 Nm

Peak torque

3.4 Nm

Nominal rotary speed

3000 rpm

Max. rotational speed

14200 rpm

Max. mechanical speed

16000 rpm

Angular acceleration

≤100000 rad/s²

Motor nominal power

350 W

Continuous stall current

2.7 A

Motor nominal current

2.4 A

Peak current

11 A

Motor constants

0.45 Nm/A

Standstill torque constant

0.53 Nm/A

Voltage constant, phase-to-phase

32 mVmin

Phase-phase winding resistance

4.85 Ohm

Winding inductance phase-phase

20 mH

Winding longitudinal inductivity Ld (phase)

8 mH

Cross inductivity Lq (phase)

10 mH

Electric time constant

2.7 ms

Thermal time constant

41 min

Thermal resistance

1.1 K/W

Measuring flange

250 x 250 x 15 mm, steel

Total output inertia moment

0.286 kgcm²

Product weight

1530 g

Permissible axial shaft load

70 N

Permissible radial shaft load

350 N

Rotor position sensor

Safety encoder, absolute multi-turn

Rotor position sensor for manufacturer designation

EQI 1131

Rotor position encoder for absolutely detectable revolutions

4096

Rotor position sensor interface

EnDat® 22

Rotor position sensor measuring principle

Inductive

Rotor position encoder for DC operating voltage

5 V

Rotor position encoder for DC operating voltage range

3.6 V ... 14 V

Rotor position encoder for positional values per revolution

524288

Rotor position sensor resolution

19 bit

Rotor position encoder system accuracy angle measurement

-120 arcsec ... 120 arcsec

Safety device

Safety device

maximum SIL

Security integrity level 3

See user documentation

Safety sub-functions up to SIL2

Reliable acquisition and transmission of single-turn position data

Safety sub-functions up to SIL3

Reliable recording and transmission of single-turn position data, only

with additional software function in the servo drive

maximum PL and category

Performance level e, category 3

See user documentation

12/30/25 - Subject to change - Festo SE & Co. KG

2/3
