AD8675
Rev. A | Page 6 of 12
TYPICAL PERFORMANCE CHARACTERISTICS
±15 V and ±5 V, TA = 25°C, unless otherwise specified.
10
9
8
7
6
5
4
3
2
1
0
1
10
100
1k
10k
100k
FREQUENCY (Hz)
Figure 3. Voltage Noise Density vs. Frequency
50
45
40
25
30
35
20
15
10
5
0
OFFSET VOLTAGE (µV)
Figure 4. Input Offset Voltage Distribution
25
20
15
10
5
0
TCVOS (µV/°C)
Figure 5. TCVOS
150
100
50
0
–100
–50
–150
–200
–40
25
125
TEMPERATURE (°C)
Figure 6. Offset Voltage vs. Temperature
120
100
80
60
40
20
0
IB (nA)
VS = ±15V
TA = 25°C
Figure 7. Input Bias Current, VS = ±15 V
160
120
140
100
80
60
40
20
0
IB (nA)
VS = ±5V
TA = 25°C
Figure 8. Input Bias Current, VS = ±5 V
