Figure 8.68 FRQDTR Sequence (without command decode cycles)

CE #

SCK

3-byte Address

Mode 3

Mode 0

20 16 12

5 1

21 17 13

4 0

IO0

IO1

22 18 14

23 19 15

8 4

9 5

10 6

11 7

6 Dummy Cycles

IO2

IO3

6 2

7 3

5 1

4 0

6 2

7 3

5 1

4 0

6 2

7 3

5 1

4 0

6 2

7 3

Data

Out

Data

Out

Data

Out

Data

Out

5 1

4 0

6 2

7 3

Mode Bits

...

Notes:

1. If the mode bits=AXh (

where X is don’t care), it will keep executing the AX read mode (without command). When the

mode bits are different from AXh, the device exits the AX read operation.

2. Number of dummy cycles depends on clock speed. Detailed information in Table 6.11 Read Dummy Cycles.

3. Sufficient dummy cycles are required to avoid I/O contention. If the number of dummy cycles and AX bit cycles are

same, then X should be Hi-Z.
