LS5018B
LS5060B/LS5120B
®
DIL8
TRISIL
TM
BIDIRECTIONAL CROWBAR PROTECTION.
BREAKDOWN VOLTAGES RANGE:
18V, 60V and 120V.
HOLDING CURRENT = 200mA min.
HIGH SURGE CURRENT CAPABILITY
IPP = 100A
10/1000
µs
FEATURES
The LS50xxB series has been designed to protect
telecommunication equipment against lightning
and transients induced by AC power lines.
Its high surge current capability makes the
LS50xxB a reliable protection device for very ex-
posed equipment, or when series resistors are
very low.
DESCRIPTION
CCITT K17 - K20
10/700
µs
1.5 kV
5/310
µs38 A
VDE 0433
10/700
µs2 kV
5/200
µs50 A
CNET
0.5/700
µs
1.5 kV
0.2/310
µs38 A
COMPLIES WITH THE FOLLOWING STANDARDS:
1
2
3
4
5
6
7
8
SCHEMATIC DIAGRAM
Symbol
Parameter
Value
Unit
IPP
Peak pulse current
10/1000
µs
8/20
µs
100
250
A
ITSM
Non repetitive surge peak on-state
current
tp = 20 ms
50
A
dI/dt
Critical rate of rise of on-state current
Non repetitive
100
A/
µs
dV/dt
Critical rate of rise of off-state voltage
VRM
5
kV/
µs
Tstg
Tj
Storage and operating junction temperature range
- 40 to + 150
150
°C
°C
TL
Maximum lead temperature for soldering during 10s
230
°C
ABSOLUTE MAXIMUM RATINGS (Tamb =25
°C)
September 1998 Ed : 3A
1/5
