Engineering Evaluation Board

Engineering Evaluation Board

The engineering evaluation board provides for a RS232

connection using a PIC microcontroller as the interface

between the HRF-ROC09325 and the RS232 port. Using

the software provided and a PC, control of test data,

operating frequency, power levels and all internal

registers

is

available

for

early

product

development/prototyping.

The board operates from a

single +6 to +9 volt supply and provides separate RF

Rx/Tx ports.

Ordering Information

Ordering Number

Product

HRF-ROC09325-B

HRF-ROC09325-T

HRF-ROC09325-E

Delivered In Chip Tubes

Delivered On Tape And Reel

2

Engineering Evaluation Board

Note 2: Contact Honeywell for details
