TDA8191
TV SOUND CHANNEL
September 1993
.
HIGH SENSITIVITY
.
EXCELLENT AM REJECTION
.
DC VOLUME CONTROL
.
PERITELEVISION FACILITY
.
4W OUTPUT POWER
.
LOW DISTORTION
.
THERMAL PROTECTION
.
TURN-ON AND TURN-OFF MUTING
DIP20
(Plastic Package)
ORDER CODE : TDA8191
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
SOUND IF INPUT
IF DECOUPLING
GND
DETECTOR (FM)
DETECTOR (FM)
GND
IF DECOUPLING
AF PA INPUT
AF PA FEEDBACK
SUPPLY VOLTAGE
AF PA OUTPUT
GND
DCVC OUTPUT
GND
TURN-ON AND TURN-OFF MUTING
DEEMPHASIS AND AF OUT
AF INPUT
VOLUME CONTROL
FUNCTION SWITCH
REF. VOLTAGE
PIN CONNECTION
DESCRIPTION
The TDA8191 is a monolithic integrated circuit that
includes all the functions needed for a complete TV
sound channel. The TDA8191 is assembled in a 20
pin dual in line power package.
1/6
