WS10-375-R1K Datasheet(PDF) 2 Page - ASM GmbH |
|
|
|||||||||||||||||||||||||||||
WS10-375-R1K Datasheet(HTML) 2 Page - ASM GmbH |
|
|
2 / 10 page  ASM CAT-WS-E-05 9 www.asm-sensor.com Dimensions informative only. For guaranteed dimensions consult factory Cable Forces typical at 20 °C Range Maximum pull-out force Minimum pull-in force mm [N] [N] 100 4.7 3.0 125 4.6 2.4 375 7.4 3.9 500 5.5 2.8 750 7.6 3.8 1000 5.3 2.9 1250 4.6 2.4 Dimensions (mm) Range A B, C D (ADSI16) 375; 750 12.5 B=31, C=38.5 93.5 (120.5) 100; 125; 500 8.0 1000; 1250 8.0 Outline drawing Model WS10 with analog or SSI output Option SB0 |
|
|
