AD8363ACPZ-R7 datasheet(3/36 Pages) AD

3 / 36 page

AD8363

Rev. 0 | Page 3 of 36

SPECIFICATIONS

VPOS = 5 V, TA = 25°C, ZO = 50 Ω, single-ended input drive, VOUT connected to VSET, VTGT = 1.4 V, CLPF = 3.9 nF, CHPF = 2.7 nF, error

referred to best-fit line (linear regression) from −20 dBm to −40 dBm, unless otherwise noted. Negative current values imply that the

AD8363 is sourcing current out of the indicated pin.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION

Maximum Input Frequency

GHz

RF INPUT INTERFACE

INHI (Pin 14), INLO (Pin 15), ac-coupled

Input Resistance

Single-ended drive

Common-Mode DC Voltage

2.6

100 MHz

TCM1 (Pin 16) = 0.47 V, TCM2 (Pin 1) = 1.0 V, INHI input

Output Voltage: High Power In

PIN = −10 dBm

2.47

Output Voltage: Low Power In

PIN = −40 dBm

0.92

±1.0 dB Dynamic Range

CW input, TA = 25°C

Maximum Input Level, ±1.0 dB

dBm

Minimum Input Level, ±1.0 dB

−56

dBm

Deviation vs. Temperature

Deviation from output at 25°C

−40°C < TA < +85°C; PIN = −10 dBm

−0.2/+0.3

−40°C < TA < +85°C; PIN = −40 dBm

−0.5/+0.6

Logarithmic Slope

51.7

mV/dB

Logarithmic Intercept

−58

dBm

Deviation from CW Response

13 dB peak-to-rms ratio (W-CDMA), over 40 dB dynamic range

<±0.1

12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range

<±0.1

14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic

range

<±0.1

256 QAM, CF = 8 dB, over 40 dB dynamic range

<±0.1

Input Impedance

Single-ended drive

49 − j0.09

900 MHz

TCM1 (Pin 16) = 0.5 V, TCM2 (Pin 1) = 1.2 V, INHI input

Output Voltage: High Power In

PIN = −15 dBm

2.2

Output Voltage: Low Power In

PIN = −40 dBm

0.91

±1.0 dB Dynamic Range

CW input, TA = 25°C

Maximum Input Level, ±1.0 dB

−2

dBm

Minimum Input Level, ±1.0 dB

−56

dBm

Deviation vs. Temperature

Deviation from output at 25°C

−40°C < TA < +85°C; PIN = −15 dBm

+0.6/−0.4

−40°C < TA < +85°C; PIN = −40 dBm

+0.8/−0.6

Logarithmic Slope

51.8

mV/dB

Logarithmic Intercept

−58

dBm

Deviation from CW Response

13 dB peak-to-rms ratio (W-CDMA), over 40 dB dynamic range

<±0.1

12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range

<±0.1

14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic

range

<±0.1

256 QAM, CF = 8 dB, over 40 dB dynamic range

<±0.1

Input Impedance

Single-ended drive

60 − j3.3
