Unit：mm

FF34 Series

◎ Specifications and/or dimenssions in this catalogue are subject to change without notice.

 Your catalogue checking the latest speifications with our drawings would be highly appreciated.

○CE-ATA 8Bit Standard Connector【HOST】

2

FF34-18 A -R11B

①②

③

④ ⑤ ⑥ ⑦

2.05

2.05

10.90

No.1 Contact

No.18 Contaact

0.40

3.40

4.20

4.20

10.87

11.90

0.10 X

X

2.98

3.40

3.40

0.10 X

・Recommended Adhesive：Heat Curing Adhesive

・Recommended FPC Plating：Au over Ni Plating

Y

X

0.40

3.40

4.20

10.050.05

4.20

3.40

0.20

0.270.03

0.06 X

0.200.03

Supporting Tape

4-R0.200.05

No.1 Contact

2-R0.200.05

0.700.05

0.10 Y

0.700.05

0.10 X

Recommended FPC Dimensions

Recommended PCB Dimensions

Pattern Prohibition Area

X

0.04 X

6.80

0.40

2.05

2.05

0.04 X

0.230.03

0.450.05

10.90

Part Number

① Series

FF34

② Number of Contact

18 : 18 Contacts

③ Contact Posision

A：Upper and Lower Contact

④ Contact Style

R：Right Angle

⑤ Contact Pitch

1：0.4mm

⑥ Contact Plating

1：Au(Flash) over Ni Plating

⑦ Lock Lever Type

B：with Cable Lock
