FEATURES

MECHANICAL DATA

PSL32 thru PSL34

SILICON EPITAXIAL PLANER TYPE

Low VF Chip Schottky Diodes

o

MAXIMUM RATINGS (at TA=25 C unless otherwise noted)

UNITS

SYMBOL

IO

IR

IFSM

CJ

RJA

TSTG

Min.

Typ.

Max.

PARAMETER

CONDITIONS

8.3ms Single Half Sine-Wave Superimposed

on Rated Load (JEDEC Method)

0

VR=VRRM TA=25 C

0

VR=VRRM TA=100 C

Junction to ambient

F=1MHz and applied 4vDC reverse voltage

-55

50

300

3.0

80

1.0

10

+150

mA

A

0C / W

pF

0C

SYMBOLS

MARKING CODE

Operating Temperature

0

(C)

-55 to + 125

*1 Repetitive peak reverse peak reverse

*2 RMS voltage

*3 Continuous reverse voltage

*4 Maximum forward voltage

20

30

40

14

21

28

20

0.38

30

0.40

40

0.40

Plastic package has Underwriters Laboratory

Flammability Classification 94V-0 Ufizing Flame

Retardant Epoxy Molding Compound.

For surface mounted applications.

Exceeds environmental standards of ML-S-19500/228

Low leakage current

See Fig.2

SMC/DO-214AB

Case JEDEC D0-214AB/SMC molded plastic

Terminals Solder plated, solderable per

MIL-STD-750, Method 2026

Polarity Indicated by cathode band

Mounting Position Any

Weight 0.195gram

PSL32

PSL33

PSL34

SL32

SL33

SL34

*1

VRRM

(V)

*2

VRMS

(V)

*3

VR

(V)

*4

VF

(V)

Forward rectified current

Forward surge current

Reverse current

Thermal resistance

Diode junction capacitance

Storage temperature

0.283(7.2)

0.260(6.6)

0.012(0.3) Typ .

0.189(4.8)

0.165(4.2)

0.244(6.2)

0.228(5.8)

0.098(2.5)

0.075(1.9)

0.040 (1.0) Typ .

0.040(1.0) Typ .

0.152(3.8)

0.144(3.6)

0.032(0.8) Typ .

Dimensions in inches and (millimeters)
