Specifications for the RF-5800-RU

Specifications subject to change without notice.

Frequency Range

30-50 MHz and 65-108 MHz

Net Presets

25

Transmission Modes

FM analog voice

FSK 16 kbps CVSD voice

FSK 16 kbps Data (synchronous)

RF Input/Output

50 Ohms nominal, unbalanced

Impedance

Power Input

10.5 - 34.5 VDC

Size

(maximum envelope)

3.2H x 10.5W x 9.6D inches

(w/o battery case)

Weight

9.8 lbs. (w/o batteries or

battery case)

Color/Finish

CARC green 383

Operating

-20 to +60 C operation

Temperature

-31 to +60 C derated

-31 to +70 C storage

Test Method

MIL-STD-810F

Immersion

3 feet (1 meter)

Altitude

Up to 15,000 ft. (4,500 m)

Sensitivity: FM

-114 dBm for 12 dB SINAD

Squelch

Selectable: noise/tone

Power Output

0.2, 1.5, and 4 Watts (user selectable)

Frequency Stability

5 ppm

Harmonic Suppression

Greater than -47 dBc (second

and third), -57 dBc all others

Spurious Suppression

Greater than 50 dBc

Environmental

Transmitter

Receiver

General

■

Single package retransmission

capability

■

Rugged, small, and lightweight

“Set-and-Forget” capability

■

PIN-accessible keypad lock with

screen blanking

Standard Features

■

Lack of cryptographic content

precludes the need for physical

security

■

■

Deployable antenna masts with

co-linear mounts

■

RF-5211-VSM050 vehicular shock mount

■

RF-5870-VM001 shock mount

■

RF-5870-VM002 shock mount locking kit

(for the RF-5870-VM001)

Optional Accessories

■

RF-5850-PS001 battery eliminator

■

BB series batteries

■

RF-6550V radio programming

application

■

Solar power option

■

Battery Case

■

Operator’s Manual

Included with Retransmission Unit
