14
TPR0441BX–SMS–09/09
ATVaultIC460
3.4.2
SPI Timings
The table below describes the requirements for devices connected to the SPI. The
ATVaultIC460 SPI meets or exceeds these requirements under the noted conditions.
See Figure 3-2 for details.
Table 3-5.
SPI Timing Parameters
Figure 3-2.
SPI Timings
See figure
Description
Condition
Min
Typ
Max
Unit
9SS low to out
TBD
ns
10
SCK period
TBD
ns
11
SCK high/low
TBD
ns
12
Rise/Fall time
TBD
ns
13
Setup
TBD
ns
14
Hold
TBD
ns
15
SCK to out
TBD
ns
16
SCK to SS high
TBD
ns
17
SS high to tri-state
TBD
ns
18
SS low to SCK
TBD
ns
MI SO
(Data Output)
SCK
(CPOL = 1)
MO SI
(Data Input)
SCK
(CPOL = 0)
SS
MSB
LSB
LSB
MSB
...
...
10
11
11
12
13
14
17
15
9
