MOF-R3C6 Datasheet(PDF) 1 Page - Unity Opto Technology |
|
|
|||||||||||||||||||||||||||||
MOF-R3C6 Datasheet(HTML) 1 Page - Unity Opto Technology |
|
|
1 / 4 page  Fiber Optic Receiver MOF-R3C6 Features 1.Uni-directional data transmission using plastic fiber 2.Signal transmission speed :MAX. 13.2 Mbps (NRZ signal) 3.Operating voltage :4.75 to 5.25 V 4.TTL compatible 5.Suitable for MOF-T3C6 Transmitter Absolute Maximum Ratings Symbol Rating Unit Supply voltage Vcc -0.5 to + 6 V High Level Output Current IOH -1 mA Low Level Output Current IOL 5mA Operating temperature Topr -20 to +70 oC Storage temperature Tstg -30 to +80 oC Soldering Temperature TSOL 260* oC * For 5s (1 times or less) REV: A1 03/22/2002 Parameter Unity Opto Technology Co., Ltd. @ TA=25 oC NOTES: Tolerance is ±0.3mm unless otherwise noted. Recommended drilling as viewd from the soldering face Outline Dimensions 1/4 |
