background image
R
版本：201007A
1/14
N 沟道增强型场效应晶体管
N-CHANNEL MOSFET
JCS830
订 货 型 号
Order codes
印
记
Marking
封
装
Package
无卤素
Halogen Free
包
装
Packaging
器件重量
Device Weight
JCS830V-O-V-N-B
JCS830V
IPAK
否
NO
条管
Tube
0.35 g(typ)
JCS830R-O-R-N-B
JCS830R
DPAK
否
NO
条管
Tube
0.30 g(typ)
JCS830S-O-S-N-B
JCS830S
TO-263
否
NO
条管
Tube
1.37 g(typ)
JCS830B-O-B-N-B
JCS830B
TO-262
否
NO
条管
Tube
1.71 g(typ)
JCS830C-O-C-N-B
JCS830C
TO-220C
否
NO
条管
Tube
2.15 g(typ)
JCS830F-O-F-N-B
JCS830F
TO-220MF
否
NO
条管
Tube
2.20 g(typ)
主要参数
MAIN
CHARACTERISTICS
ID
4.5 A
VDSS
500 V
Rdson（@Vgs=10V） 1.5 Ω
Qg
32 nC
用途
高频开关电源
电子镇流器
UPS 电源
APPLICATIONS
High efficiency switch
mode power supplies
Electronic lamp ballasts
based on half bridge
UPS
产品特性
低栅极电荷
低
Crss (典型值 17pF)
开关速度快
产品全部经过雪崩测试
高抗
dv/dt 能力
RoHS 产品
FEATURES
Low gate charge
Low Crss (typical 17pF )
Fast switching
100% avalanche tested
Improved dv/dt capability
RoHS product
订货信息 ORDER MESSAGE
封装 Package
